10mm DC Motor Sizing Tool and Decision Report (includes `10mm brushed motor` alias intent)
Use one canonical URL to finish two tasks in sequence: get an immediate motor-fit estimate, then verify decision quality with evidence, boundaries, alternatives, and risk controls.
Published: 2026-04-23 | Last updated: 2026-04-23 | Review cadence: quarterly
Tool layer: quick sizing input
Enter boundary-safe values first. Invalid input is blocked and recoverable.
Result layer: interpreted outputNo result yet
Result includes interpretation, uncertainty, and the next executable action.
Empty state
No calculation yet. Enter inputs and run the estimator to generate a fit decision.
Stage1b gap audit and closure status
Audit-first enhancement: each high-impact content gap is tracked with explicit remediation status.
Gap closure ledger
Blocker/high gaps are closed in-page; unresolved items remain explicitly marked for follow-up.
| Gap found | Decision impact | Stage1b action | Status |
|---|---|---|---|
| Alias phrase `10mm brushed motor` was not explicitly answered in core sections. | High risk of intent mismatch and route-level ambiguity for do+know traffic. | Added alias phrase in heading, FAQ, anchor block, and route metadata while keeping a single canonical URL. | Closed in stage1b |
| Current-output interpretation did not distinguish driver RMS thermal limits vs startup peak limits. | High risk of selecting motor-driver combinations that pass bench startup but fail thermal soak. | Added DRV8833 1.5A RMS / 2A peak boundary notes and RMS-loss interpretation in method + tool output. | Closed in stage1b |
| Direct-drive reference lacked lifecycle and hard envelope cues (NRND, max speed, ambient/winding limits). | High risk of using reference PN as a default production choice without availability/thermal checks. | Added RE10 lifecycle caveat and 14k rpm / -20..+65C ambient / +85C winding guardrails. | Closed in stage1b |
| GPX10 gearhead values were shown without catalog-status warning. | Medium-to-high risk of freezing RFQ assumptions on provisional catalog figures. | Marked GPX10 row as provisional data subject to change and moved final commitment to supplier quotation package. | Closed in stage1b |
| RoHS disclosure only highlighted Pb/Cd and skipped phthalate rows and effective dates. | High risk of incomplete compliance document requests in production RFQ stage. | Added Directive (EU) 2015/863 Annex II 10-substance scope and 2019/2021 applicability milestones. | Closed in stage1b |
| Public standard for `10mm brushed motor` nomenclature-to-performance mapping is absent. | Medium risk of treating vendor alias phrase as an engineering standard. | Marked as pending and required PN-level datasheet + drawing package before release. | Open (evidence pending) |
Report summary: conclusions and key numbers
Core conclusions are paired with quantifiable context before deep-dive sections.
Canonical query volume
20 / month
`10mm dc motor` (US keyword snapshot, 2026-03-29).
Alias query volume
10 / month
`10mm brushed motor` is merged into this canonical URL.
Gear ratio envelope
4:1 to 1024:1
maxon GPX10 catalog page (2025-03, provisional data).
10mm direct-drive reference
1.55 mNm nominal
maxon RE10, 6V reference point (accessed 2026-04-23).
Driver current boundary
1.5A RMS / 2A peak
TI DRV8833 product page (updated 2025-08-15, accessed 2026-04-23).
Reference lifecycle caveat
RE10 PN256105: NRND
maxon flags this PN as not recommended for new designs (accessed 2026-04-23).
Who this is suitable for
- Need a fast pre-RFQ shortlist for 10mm brushed dc direct-drive vs geared options.
- Need to verify whether a 10mm brushed motor should stay direct-drive or move to a gearhead.
- Need output-speed/torque feasibility check before choosing ratio and driver class.
- Need one decision memo with alias intent, evidence boundaries, and sourcing actions.
Who this is not suitable for
- Safety-critical products needing certified thermal/lifetime tests.
- Projects requiring guaranteed output-speed tolerance without supplier test data.
- Applications with explosive atmosphere compliance or IP67 guarantee.
- Mass production release without bench validation and sample approval.
Methods and evidence
Transparent formulas, dated sources, and explicit known/unknown boundaries.
Method flow
Input to estimate to boundary check to action path.
| Method block | Formula / rule | Decision value |
|---|---|---|
| Mechanical power estimate | P = 2 * pi * n / 60 * T | Converts speed and torque into shaft mechanical load. |
| Rated current estimate | I = P / (V * eta) + I_idle | Adds efficiency + idle current to avoid optimistic sizing. |
| Geared output speed estimate | n_out ~= n_motor / i | Provides first-pass speed estimate before tolerance and load corrections. |
| Startup surge estimate | I_start ~= 2.4 * I_rated | Used for driver and power rail margin planning. |
| Driver thermal check | P_driver ~= I_rms^2 * RDS(on) | RMS current governs thermal stress; peak-current labels are not continuous-use guarantees. |
| Direct-drive speed margin | speed_margin = n_ref_max - n_target | Flags when target speed exceeds RE10-class 14k rpm reference envelope. |
| Nominal-to-exact ratio guardrail | n_out exact ~= n_motor / i_exact | For high-ratio gearheads, use exact ratio and tolerance instead of nominal shorthand. |
| Confidence score | Base 91 - condition penalties | Reduces confidence in high duty, high heat, low voltage cases. |
Source ledger
Time markers and certainty labels are mandatory for trust. Last refreshed: 2026-04-23.
| Source | Date | Coverage | Known / Unknown |
|---|---|---|---|
| data/keywords/10mm-motor_triage_fixed.csv | 2026-03-29 | Canonical volume/CPC and alias mapping context. | Known |
| data/keywords/10mm-motor_queue.alias-merge-checklist.csv | 2026-03-29 | Alias `10mm brushed motor` -> `/learn/10mm-dc-motor`. | Known |
| OpenSpec changes: add-kw-10mm-dc-motor-page + add-kw-10mm-brushed-motor-page | 2026-04-23 | No standalone alias route; canonical-only decision. | Known |
| maxon RE10 product page (Part No. 256105) | Accessed 2026-04-23 | 6V reference with 12,500 rpm no-load speed, 14,000 rpm max speed, 1.55 mNm nominal torque, 0.36A stall current, and NRND lifecycle flag. | Known |
| maxon GPX10 catalog page (EN-373) | Accessed 2026-04-23 | Ratio range 4:1-1024:1; stage-count trend for efficiency/backlash and torque limits; catalog page marks data as provisional. | Known with provisional boundary |
| Pololu micro metal gearmotor product guide | Accessed 2026-04-23 | Nominal 1000:1 maps to exact 986.41:1; no-load speed +/-20%; stall current +/-50%; recommended continuous load <=25% of stall current. | Known with vendor scope |
| FAULHABER Precision Gearheads Technical Information | Accessed 2026-04-23 | Exceeding continuous torque can reduce service life; intermittent torque mode requires strict duty-cycle constraints. | Known with boundary |
| FAULHABER DC Motors Technical Information | Accessed 2026-04-23 | Brushed-motor service-life order of magnitude (about 1,000-10,000 h) and PWM recommendation at/above 20 kHz. | Known with scope |
| TI DRV8833 product page + datasheet | Accessed 2026-04-23 | VM range 2.7V-10.8V, full-scale output current 1.5A RMS, peak output current 2A, and 360mOhm HS+LS RDS(on) at 25C. | Known |
| TI Application Report SLVA505A | Published 2024-07 (accessed 2026-04-23) | Driver current limits are thermally constrained by RMS current and conduction losses scale with I^2 * RDS(on). | Known |
| EUR-Lex Directive 2011/65/EU (RoHS baseline) | Accessed 2026-04-23 | RoHS framework and Annex II concentration-limit structure for homogeneous materials. | Known |
| EUR-Lex Directive (EU) 2015/863 | Accessed 2026-04-23 | Annex II expanded to 10 substances including DEHP/BBP/DBP/DIBP at 0.1%; general applicability from 2019-07-22 and medical/monitoring categories from 2021-07-22. | Known |
| On-page sizing model (this tool) | 2026-04-23 | Pre-RFQ current/power/fit scoring; not a substitute for PN-level endurance validation. | Known |
| Cross-vendor standard mapping `10mm brushed motor` query wording to electrical/thermal limits | Pending | No reliable public standard dataset found; vendor PNs remain authoritative. | Pending confirmation / no reliable public dataset |
Stage1b research delta
Only net-new, source-verifiable information is included here. Each row states scope and decision consequence.
New evidence-backed decision facts
Update date: 2026-04-23. Facts without stable public evidence stay in the pending block.
| Topic | New fact | Applicable condition | Decision effect | Certainty |
|---|---|---|---|---|
| 10mm direct-drive boundary | maxon RE10 reference shows 12,500 rpm no-load, 14,000 rpm max speed, and ambient/winding limits (-20..+65C ambient, +85C winding max). | Reference is one public PN, used as a class-level boundary indicator rather than a universal motor limit. | When requirements push beyond this speed/thermal envelope, shift to geared or alternative frame paths before RFQ freeze. | Known |
| Reference lifecycle caveat | maxon marks RE10 Part No. 256105 as NRND (not recommended for new designs). | NRND status is PN-specific and does not invalidate class-level physics guidance. | Treat this PN as boundary reference only and request active-production alternatives in RFQ packs. | Known |
| 10mm gear ratio envelope + data status | maxon GPX10 catalog shows reductions from 4:1 to 1024:1 and explicitly labels page data as provisional. | Catalog values remain platform-specific and are subject to final quotation/package updates. | Use ratio-stage planning early, but lock commitments only after supplier-confirmed technical offer. | Known with provisional boundary |
| Nominal-ratio counterexample + stall-current margin | Pololu guidance shows nominal 1000:1 equals exact 986.41:1, no-load speed tolerance near +/-20%, and recommends <=25% stall current for continuous operation. | Tolerance and load guidance are vendor-family-specific but directly illustrate common micro-gearmotor pitfalls. | Do not commit exact output rpm from nominal labels and avoid designing continuous operation close to stall regions. | Known with vendor scope |
| Driver capability boundary | TI DRV8833 guidance lists 1.5A RMS continuous and 2A peak output current with 360mOhm combined HS+LS on-resistance. | Applies when DRV8833-class topology is selected for brushed 10mm systems. | Map estimator rated current to RMS limit and startup surge to peak limit before driver selection is frozen. | Known |
| Driver thermal interpretation rule | TI SLVA505A states motor-driver thermal stress is governed by RMS current and conduction losses scale with I^2 * RDS(on). | Rule is generic to MOSFET-based H-bridges and should be applied alongside each driver datasheet. | Do not treat peak-current labels as steady-state capability; run thermal checks on RMS current profile. | Known |
| Gearhead duty-cycle boundary | FAULHABER guidance keeps intermittent operation separate from continuous ratings and requires strict duty limits for overload use. | Applies as boundary guidance; exact duty allowances vary by gearhead family. | Request continuous/intermittent torque tables tied to your duty profile before purchase decisions. | Known with boundary |
| RoHS scope boundary | Directive (EU) 2015/863 extends Annex II to 10 restricted substances, including four phthalates at 0.1%, with staged applicability dates in 2019 and 2021. | Applies to covered EEE categories and relevant exemption context. | RFQ compliance packs must include phthalate declarations, not just Pb/Cd/Hg style metal declarations. | Known |
Pending confirmation / no reliable public data
Evidence is insufficient for strong conclusions in these areas.
| Open question | Why evidence is insufficient | Decision impact |
|---|---|---|
| Cross-vendor, normalized life curves for 10mm brushed dc gearmotor outputs under matched duty/load profiles. | Public datasets use different rigs, lubrication packages, and load profiles. | Cannot issue strong life claims; procurement should require PN-level endurance report. |
| Public standard linking alias phrase `10mm brushed motor` to guaranteed electrical/thermal limits. | No reliable cross-vendor public standard was identified in this iteration. | Alias-wording-only purchasing remains high-risk without PN-level datasheets. |
| Backlash growth vs service life across different 10mm gearhead platforms. | Most public publications report initial backlash but not life-cycle drift under matched duty. | Backlash-sensitive applications need vendor endurance data before freezing architecture. |
| Cross-vendor, publicly maintained replacement matrix for NRND 10mm brushed direct-drive references. | Lifecycle disclosures are vendor-specific and not normalized into a common public interchangeability dataset. | Procurement must request active-PN alternatives and approval samples instead of relying on reference PN continuity. |
Alternative comparison
Use reproducible dimensions (voltage, torque, response, cost, fit) instead of generic claims.
Option comparison table
If a value is unavailable in your project context, keep it as N/A and request supplier evidence.
| Option | Voltage band | Torque band | Dynamic response | Cost class | Best-fit scenario | Boundary / counterexample |
|---|---|---|---|---|---|---|
| 10mm brushed dc direct drive (RE10-class reference) | 3V-6V | 1-8 mNm (class-level planning range) | Very fast | Low to medium | Good for compact high-speed, low-load tasks | Counterexample: sustained medium/high torque requests usually require gearing or larger frame; RE10 reference PN itself is NRND. |
| 10mm brushed dc + GPX10-class gearhead | 3V-6V | 35-1000 mNm (catalog stage-dependent) | Medium | Medium | Good when output torque and lower output rpm dominate requirements | High ratio adds efficiency/backlash penalties; do not treat nominal ratio as exact output guarantee; catalog values are provisional. |
| 10x12 micro metal gearmotor class (commodity reference) | 3V-6V | Vendor- and ratio-specific | Fast | Low to medium | Useful for cost-sensitive builds needing common ratio options | Ratio nomenclature and tolerance must be read from exact-ratio tables, not nominal labels alone; continuous load should stay well below stall-current regions. |
| Mini BLDC + gearhead | 5V-12V | 15-120 mNm (architecture-dependent) | Fast | Medium to high | Better lifetime/noise at the cost of controller complexity | Often unsuitable for low-voltage and cost-constrained 10mm programs. |
Risk and mitigation
Covers misuse risk, cost risk, and scenario mismatch risk with direct mitigation actions.
Risk matrix
| Risk | Impact | Probability | Mitigation path |
|---|---|---|---|
| Treating `10mm brushed motor` alias phrase as a standardized performance specification | High | Medium | Require PN-level datasheet + drawing package and verify electrical constants before RFQ freeze. |
| Selecting ratio by nominal label only (ignoring exact ratio and tolerance) | High | High in high-ratio requests | Translate nominal ratio into exact-ratio/tolerance output-speed range and validate on load. |
| Interpreting driver peak-current rating as continuous current capability | High | Medium | Map estimated rated current to RMS limits and startup surge to peak limits, then run thermal checks with I^2 * RDS(on). |
| Operating above continuous gearhead torque envelope | High | Medium | Use vendor continuous/intermittent torque rows and duty-cycle limits as procurement gates. |
| Undersized startup current budget | High | Medium | Reserve >=2.4x rated current on driver + power path. |
| VM droop below motor-driver floor (or UVLO threshold) | Medium | Medium | Verify driver VM minimum and transient droop on oscilloscope before architecture freeze. |
| Thermal drift at high duty cycle without endurance curves | Medium | Medium | Run duty derating and include enclosure thermal path review. |
| RoHS compliance assumed without homogeneous-material declarations | High | Medium | Collect supplier declaration and exemption mapping before production release, including phthalate rows introduced by Directive (EU) 2015/863. |
| Using provisional catalog values as frozen procurement commitments | Medium | Medium | Treat catalog numbers as planning references and lock final commitments to supplier technical offers and drawings. |
| Selecting an NRND reference PN for new mass-production plans | High | Medium | Request active-production alternatives and lifecycle statements before awarding production RFQ. |
| Alias query interpreted as separate SKU | Medium | Medium | Keep one canonical URL and answer alias intent explicitly in FAQ. |
Scenario examples
Each scenario includes assumptions, modeled output, and the minimum next action.
Scenario table
| Scenario | Assumption | Estimated result | Action |
|---|---|---|---|
| 10mm brushed motor direct-drive request with medium torque demand | 3.7V rail, 9k rpm, 12 mNm target on 10mm brushed dc without gearhead | Conditional to not recommended for continuous duty. | Evaluate geared architecture and validate thermal rise before shortlist lock. |
| High-ratio low-speed output from nominal-only ratio | Nominal 1000:1 selected without exact-ratio/tolerance conversion | Conditional fit with high spec-risk. | Recalculate with exact ratio and tolerance window, then validate output speed on load. |
| 10mm brushed motor + moderate-ratio gearhead path | 6V rail, motor 10k rpm class, 64:1 ratio target, 45% duty | Conditional fit (gearhead optional). | Request A/B samples with two ratio options and compare backlash/temperature drift. |
| Low-voltage brushed path near driver floor | 2.0V rail with DRV8833-class floor constraints and startup surge | Not recommended without power-architecture change. | Shift to compatible driver/power architecture and retest startup behavior. |
| Startup surge passes bench, but RMS current exceeds driver thermal envelope | Estimated rated current >1.5A with repetitive duty; selected driver only has 2A peak margin. | Conditional to not recommended for production without driver change. | Re-select driver on RMS thermal rating, then validate with current waveform and temperature-rise tests. |
| RFQ drafted against RE10 Part 256105 only | Program treats RE10 reference PN as default production part without lifecycle screening. | Conditional with sourcing continuity risk. | Add active-PN alternatives and lifecycle statement requirement before RFQ release. |
Alias coverage anchors
Internal anchors keep `10mm brushed motor` traffic on this canonical page without split routes.
Decision FAQ
Questions are grouped by intent, not glossary-only definitions.
B2B application fit, OEM options, and inquiry handoff
Move from estimator output to executable sourcing with factory customization scope and compliance-ready RFQ preparation.
Application fit
Projects that match this page's pre-RFQ scope.
- Teams screening 10mm brushed dc motor options for compact drivetrain programs.
- Programs consolidating `10mm dc motor` and `10mm brushed motor` on one canonical URL.
- Projects that need explicit direct-drive vs gearhead boundaries before RFQ submission.
OEM options
Customization knobs available from factory-side engineering.
- Winding/Kv and no-load-speed tuning to match your voltage and output-speed envelope.
- Gearhead ratio, stage count, backlash target, shaft geometry, and connector customization.
- Lead-wire, insulation, and packaging customization aligned to your assembly flow.
Trust and compliance
Evidence gates required before production commitment.
- Collect RoHS/REACH declarations with homogeneous-material granularity before order release.
- Validate startup surge, thermal rise, and duty-cycle life on PN-level samples.
- Keep this page as pre-RFQ guidance; final claims require manufacturer qualification files.
